Wholesale Automotive Connector
-
DT06-2S 2-Way Plug Assembly
Contact UsProduct Details
Product No
LZ7023D-1.6-21
Size(L*W*H)
28*15*14.2mm
Number of Positions
2
Gender
Plug (Female) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT04-2P 2-Way Receptacle Assembly
Contact UsProduct Details
Product No
LZ7023D-1.6-11
Size(L*W*H)：42*17*17mm
42*17*17mm
Number of Positions
2
Gender
Gender: Receptacle (Male) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT06-3S 3-Way Plug Assembly
Contact UsProduct Details
Product No
LZ7033D-1.6-21
Size(L*W*H)
28.5*18*20mm
Number of Positions
3
Gender
Plug (Female) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT04-3P 3-Way Receptacle Assembly
Contact UsProduct Details
Product No
LZ7033D-1.6-11
Size(L*W*H)
43.5*21*25mm
Number of Positions
3
Gender
Gender: Receptacle (Male) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT06-4S 4-Way Plug Assembly
Contact UsProduct Details
Product No
LZ7043D-1.6-21
Size(L*W*H)
31*18*17mm
Number of Positions
4
Gender
Plug (Female) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT04-4P 4-Way Receptacle Assembly
Contact UsProduct Details
Product No
LZ7043D-1.6-11
Size(L*W*H)
46*21*19.5mm
Number of Positions
4
Gender
Gender: Receptacle (Male) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT06-6S 6-Way Plug Assembly
Contact UsProduct Details
Product No
LZ7063D-1.6-21
Size(L*W*H)
31*14*22mm
Number of Positions
6
Gender
Plug (Female) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT04-6P 6-Way Receptacle Assembly
Contact UsProduct Details
Product No
LZ7063D-1.6-11
Size(L*W*H)
46*19*24mm
Number of Positions
6
Gender
Gender: Receptacle (Male) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT06-8S 8-Way Plug Assembly
Contact UsProduct Details
Product No
LZ7083D-1.6-21
Size(L*W*H)
30.5*30.5*19.5mm
Number of Positions
8
Gender
Plug (Female) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT04-8P 8-Way Receptacle Assembly
Contact UsProduct Details
Product No
LZ7083D-1.6-11
Size(L*W*H)
46*36*25mm
Number of Positions
8
Gender
Gender: Receptacle (Male) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT06-12S 12-Way Plug Assembly
Contact UsProduct Details
Product No
LZ7123D-1.6-21
Size(L*W*H)
31*38*18.5mm
Number of Positions
12
Gender
Plug (Female) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
-
DT04-12P 12-Way Receptacle Assembly
Contact UsProduct Details
Product No
LZ7123D-1.6-11
Size(L*W*H)
46*41*22mm
Number of Positions
12
Gender
Gender: Receptacle (Male) Pitch
5.46 mm
Connector Mounting Type
Cable Mount / Free Hanging
Termination Style
Crimp
Wire Gauge
14-20 AWG
Color
Gray
Packaging
Bulk
Application
Wire to Wire
Attachment Hole Diameter
1.6 mm
Contact Current Rating (A)
13 A
Housing Material
Polyamide (PA)
Ingress Protection
IP68, IP6K9K
Locking Mechanism
Integrated in Housing
Material
Plastic
Operating Temperature
-67°F (-55°C) to +257°F (+125°C)
Mounting Angle
Straight
Number of Rows
1 Row
Voltage Rating
250 V
Our automotive connectors are designed to meet the demanding needs of the automotive industry. With an emphasis on reliability and versatility, our range encompasses connector kits tailored to diverse automotive requirements, complemented by essential accessories like insertion and extraction tools.
Waterproof Capability:
Our Auto Connector boasts waterproof capability, making it highly reliable even in the demanding environmental conditions. Engineered with precision and expertise, it effectively prevents water ingress, safeguarding the integrity and performance of the electrical connections. Whether facing rain, moisture, or humidity, our Auto Connector ensures uninterrupted functionality, thus enhancing the overall durability and longevity of automotive systems.
Oxidative Stability:
One of the standout features of our Auto Connector is its oxidative stability. Designed to withstand the effects of oxidation over time, it maintains good performance under prolonged exposure to varying temperatures and atmospheric conditions. This inherent stability not only reduces the risk of corrosion but also contributes to the efficient operation of electrical circuits within vehicles.
High Voltage Resistance:
In addition to its nice waterproof and oxidative properties, our Auto Connector exhibits high voltage resistance, further enhancing its suitability for automotive applications. Engineered to meet stringent standards, it ensures safe and reliable electrical connections even in high-voltage environments. Whether powering essential components or transmitting critical data, our Auto Connector delivers consistent performance, thereby enhancing the overall safety and efficiency of automotive operations.
Durable Construction:
At the core of our Auto Connector lies a durable construction, meticulously crafted to withstand the rigors of automotive use. Utilizing high-quality materials and advanced manufacturing techniques, we ensure unparalleled strength and resilience in every connector produced. This robust construction not only enhances the longevity of the connector but also reduces the risk of premature failure, thereby providing customers with a dependable solution for their automotive needs.
Precision Engineering:
Precision engineering forms the cornerstone of our Auto Connector design process, ensuring good performance and compatibility with various automotive systems. Each connector is engineered with precision, taking into account factors such as tolerances, fitment, and electrical conductivity. This meticulous approach not only guarantees seamless integration but also facilitates efficient installation and maintenance, thereby reducing downtime and improving productivity for end-users.
Versatile Applications:
Our Auto Connector is designed to cater to a wide range of automotive applications, providing versatility and flexibility to meet diverse customer requirements. Whether used in passenger vehicles, commercial trucks, or industrial machinery, our connectors excel in delivering consistent performance across different operating conditions. From power distribution to signal transmission, our Auto Connector serves as a reliable interface, enabling smooth communication and operation within complex automotive systems.
Customer Satisfaction:
At the heart of our endeavors lies a steadfast commitment to customer satisfaction, driving us to continually improve and innovate our Auto Connector offerings. We place great emphasis on understanding and addressing the evolving needs of our customers, thereby fostering long-term partnerships built on trust and mutual success. Whether providing technical support, customization options, or timely delivery, we strive to exceed customer expectations at every turn, ensuring a seamless experience from procurement to implementation.
In conclusion, our Auto Connector series embodies greatness in automotive connectivity, offering waterproof capability, oxidative stability, and high voltage resistance. As a trusted partner in automotive connectivity solutions, we remain committed to delivering products that meet the evolving needs of the automotive industry, ensuring seamless integration, good performance, and reliability for our customers.
Who are we?
Wenzhou Lizone Connector Co., Ltd. is China Auto Connector manufacturers and custom Auto Connector factory, located in Yueqing City, Zhejiang Province, is the city with the earliest domestic market economy and the dynamic economic development. It is close to 104 National Highway and Yongtaiwen Expressway, Wenzhou Bridge. The North White Elephant exit is 5 kilometers away, and it is about 25 kilometers away from Wenzhou Airport and the railway station. The traffic is very convenient.
The company specializes in the production of various automotive, motorcycle electrical circuit connectors, connectors, connecting terminals, fuse boxes, fuses, wiring harnesses, lamp holders, with new product development and mold precision manufacturing for 20 years and with many domestic automotive wiring harnesses Factory supporting cooperation.
-
Industry experience
0+ -
Product
0+ -
Client
0+ -
Patent
0+
Qualifications we have obtained
Authentic reliable quality naturally stands out and fears no comparison.
News
-
-
China Wholesale Connector Components Manufacturer Factory Connector components are the unsung heroes that enable devices to commun...
READ MORE -
High Quality Connector Components Manufacturing in China Connector components are crucial elements in electrical and electronic sy...
READ MORE -
OEM High Quality Connector Components Manufacturer Exporter Connector components are fundamental elements used in electronic devic...
READ MORE
Message Feedback
